Home > Components > Nozzles > TS1175

Ribbon Nozzle 4 Inch Long x 1.75 Inch Wide

Dispensing nozzles for cartridges and valves. Industrial grade safe up to 100 psi and certified silicone-free. Threaded attachment for leak free dispensing. Ribbon nozzles offer a wider band of fluid coverage to substrates either dispensing by hand or on automated application systems.

TS1175 Ribbon Nozzle 1.75" wide Adhesive Dispensing Techcon

Precision moulded 4 Inch long spreader nozzle x 1.75 Inch wide x 1/8 Inch (0.130 Inch) orifice. 1/4 Inch NPT thread to fit cartridges, valves and with TSD931-296 for sealant cartridge adapter fitting.

Natural medium density polypropylene material safe for use up to 100 psi. 1 Inch wide opening slit provides wider spread of adhesive to products.

Supplied in sealed packs of 10. Bulk quantities are also available on request. This product is available direct from stock.

Watch the nozzle comparison video here

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

TS1175 Nozzle

GBP pack ex. Vat.
Excludes Carriage.
Lead Time: Usually Ships 24 Hours

Summary: Natural MDPE cartridge with 1/4 Inch Thread.

Item	Qty	Price GBP	Add
TS1175	10	pack

Specifications:

Materials: Medium Density Polyethlene
Colour: Natural
Opening Size: 1/8 Inch - 3.30mm
Opening Width: 1.75 Inch - 44.45mm
Total Length: 4.4 Inch - 111.7mm
Connection Type: 1/4" NPT Male Thread
Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: Spreader Nozzle
Features: Silicone-Free, Industrial Grade

Delivery: Products shipped by courier on a tracked and insured service for stock items.

Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates and updates.

Typical Applications:- Nozzles are moulded in medium density plastics and have much thicker walls than a standard silicone caulking nozzle.

All nozzles use a 1/4" NPT internal thread for leak free attachment. Use with most liquids, pastes, epoxies, gels, solvents, adhesives, fluxes, lubricants, paints, inks, solder creams, braze pastes and many more assembly fluids.

Adhesive Dispensing Cartridges Techkits Semkits Nozzles

TS1175 Nozzle Ribbon Adhesive Dispensing

TS1175 spreader nozzle Techcon adhesive dispensing

Nozzle Pages

Silicone and chloride free plastics

Industrial grade safe to 100 psi

Resistant to aggressive fluids and solvents

High density moulding (MDPE)

1/4" NPT thread to accept nozzles

Compatible with industry cartridges

Nozzle Accessories

More Info	Part No.	Specs	Colours	Lead Time	Pack	Price GBP	Add
	TS25CKIT 2.5oz Cartridge & Plunger Kit	1.59" OD/ 7.14" Long	Natural/ White	24 Hours	10	pack
	TS60CKIT 6oz Cartridge & Plunger Kit	1.59" OD/ 7.14" Long	Natural/ White	24 Hours	10	pack
	TS110CKIT 10oz Cartridge & Plunger Kit	1.85" OD/ 8.99" Long	Natural	24 Hours	10	pack
	TS120CKIT 12oz Cartridge & Plunger Kit	1.85" OD/ 12.34" Long	Natural	24 Hours	10	pack
	TS20CKIT 20oz Cartridge & Plunger Kit	2.67 OD/ 9.87" Long	Natural	24 Hours	10	pack
	TS32CKIT 32oz Cartridge & Plunger Kit	2.67 OD/ 13.75" Long	Natural	24 Hours	10	pack
	TS1WP Cartridge Plunger 2.5, 6, 8, 12oz	1.59" OD	Natural	24 Hours	10	pack
	TS1P Cartridge Plunger 2.5, 6, 8, 12oz	1.59" OD	Blue	24 Hours	10	pack
	TS1PB Cartridge Plunger 2.5, 6, 8, 12oz	1.59" OD	Black	24 Hours	10	pack
	TS1WP-RIB Cartridge Plunger 2.5, 6, 8, 12oz	1.59" OD	Natural	24 Hours	10	pack
	TS2C End Cap 2.5, 6, 8, 12oz Cartridges	1.59" OD	Red	24 Hours	10	pack
	TS3P Tip Cap Threaded Seal All Sizes	21mm Dia.	Red	24 Hours	10	pack
	TS6P-RED Tip Cap Threaded Seal All Sizes	20mm Dia.	Red	24 Hours	10	pack
	TS216 Standard Nozzle	2.5" L x 1/16" ID HDPE	Natural	24 Hours	10	pack
	TS218 Standard Nozzle	2.5" L x 1/8" ID HDPE	Natural	24 Hours	10	pack
	TS218-LD Standard Nozzle	2.5" L x 1/8" ID LDPE	Natural	24 Hours	50	pack
	TS416 Standard Nozzle	4.0" L x 1/16" ID HDPE	Natural	24 Hours	10	pack
	TS416-LD Standard Nozzle	4.0" L x 1/16" ID LDPE	Natural	24 Hours	50	pack
	TS418 Standard Nozzle	4.0" L x 1/8" ID HDPE	Natural	24 Hours	10	pack
	TS432 Standard Nozzle	4.0" L x 1/32" ID HDPE	Natural	24 Hours	10	pack
	TS432-LD Standard Nozzle	4.0" L x 1/32" ID LDPE	Natural	24 Hours	50	pack
	TS490 Standard Nozzle	4.0" L x 3/32" ID HDPE	Natural	24 Hours	10	pack
	TS1050 Ribbon Spread Nozzle	4.0" L x 0.50" W HDPE	Natural	24 Hours	10	pack
	TS1075 Ribbon Spread Nozzle	4.0" L x 0.75" W HDPE	Natural	24 Hours	10	pack
	TS1100 Ribbon Spread Nozzle	4.0" L x 1.0" W HDPE	Natural	24 Hours	10	pack
	TS1175 Ribbon Spread Nozzle	4.0" L x 1.75" W HDPE	Natural	24 Hours	10	pack
	AD16-25 Manual Cartridge Gun 2.5oz	Hand Operated	Black	24 Hours	1	each
	AD16-60 Manual Cartridge Gun 6oz	Hand Operated	Black	24 Hours	1	each
	AD16-80 Manual Cartridge Gun 8oz	Hand Operated	Black	24 Hours	1	each
	AD16-110 Manual Cartridge Gun 10oz	Hand Operated	Black	24 Hours	1	each
	AD16-120 Manual Cartridge Gun 12oz	Hand Operated	Black	24 Hours	1	each
	100A-25 Pneumatic Cartridge Gun 2.5oz	Max. 100 PSI Air	Black	24 Hours	1	each
	100A-60 Pneumatic Cartridge Gun 6oz	Max. 100 PSI Air	Black	24 Hours	1	each
	100A-80 Pneumatic Cartridge Gun 8oz	Max. 100 PSI Air	Black	24 Hours	1	each
	100A-110 Pneumatic Cartridge Gun 10oz	Max. 100 PSI Air	Black	24 Hours	1	each
	100A-120 Pneumatic Cartridge Gun 12oz	Max. 100 PSI Air	Black	24 Hours	1	each
