Home > Components > Cartridges > TS25CWP-500

2.5 Ounce HDPE Cartridge Reservoir & Plunger Kit

Cartridges are manufactured to the very highest possible quality delivering exceptional performance and consistency. From moulding to packaging, cartridges are guaranteed to be free of silicone contaminants and imperfections.

TS25CPB-LD-500 2.5oz LD Cartridge Plunger Techcon

Cartridge reservoir in high density polyethylene with wiper plunger in a kit of 10 x TS25C cartridges and 10 x TS1PB plungers. 2.5 ounce/ 75cc ml size. Suitable for handling most materials including solvent based fluids. 1.69 Inch outer diameter by 4.00 Inch long.

Suitable for use in cartridge guns or pressurised cartridge retainers and caps. Cartridges feature a 1/4 Inch NPT (6mm) female thread dispensing orifice for secure attachment of nozzles or 1/4 Inch threaded fittings.

Disposable plastic cartridges are available in 2.5, 6, 8, 12, 20, 32 oz. (approximate metric value 75, 177, 237, 355, 591, 960cc) and 1/10th gallon capacities. Manufactured in high-density natural polyethylene (HDPE).

All sizes feature a 1/4 Inch NPT (6mm) female thread dispensing orifice for secure attachment of nozzles or 1/4 Inch threaded fittings. These items ship from our UK warehouse direct from stock - no delays. We stock manual and applicator guns for these cartridges.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

TS25CWP Cartridge/ Plunger

Excludes Carriage.
Lead Time: Usually Ships 24 Hours

Summary: Natural HDPE 2.5 Ounce (75ml) size cartridge with wiper plunger kit.

Item	Qty	Price GBP	Add
TS25CWP-10	10	pack
TS25CWP-50	50	pack
TS25CWP-250	250	pack
TS25CWP-500	500	pack

Specifications

Cartridge Material: High Density Polyethlene
Plunger Material: Medium Density PE
Cartridge Colour: Natural
Plunger Colour: Black
Capacity: 2.5 Ounce (75cc or 75ml)
Outer Diameter: 42.92mm (1.69 Inch)
Inner Diameter: 40.40mm (1.59 Inch)
Total Length: 101.6mm (4.00 Inch)
Connection Type: 1/4" NPT Female Thread
Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: Sealant type cartridge
Features: Silicone-Free, Industrial Grade

Delivery: Products shipped by courier on a tracked and insured service for stock items.

Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates and updates.

Typical Applications:- Cartridges are moulded in high density plastics and have much thicker walls than a standard silicone caulking tube. The internal bore has no taper and this ensures the plunger moves consistently down without restriction.

All cartridges use a 1/4 Inch NPT internal thread for leak free nozzle attachment.

Use with most liquids, pastes, epoxies, gels, solvents, adhesives, fluxes, lubricants, paints, inks, solder creams, braze pastes and many more assembly fluids.

Adhesive Dispensing Cartridges Techkits Semkits Nozzles

Cartridge Pages

Silicone and chloride free plastics

Industrial grade safe to 100 psi

Resistant to aggressive fluids and solvents

High density moulding (HDPE)

1/4 Inch NPT thread to accept nozzles

Compatible with industry standard guns

Cartridge Accessories

More Info	Part No.	Specs	Colours	Lead Time	Pack	Price GBP	Add
	TS25C 2.5oz Cartridge	1.59" OD/ 4.00" Long	Natural	24 Hours	10	pack
	TS25CP 2.5oz Cartridge Plunger Kit	1.59" OD/ 4.00" Long	Natural/ Blue	24 Hours	10	pack
	TS25CP-LD 2.5oz Cartridge Plunger Kit	1.59" OD/ 4.00" Long	Natural/ Blue	72 Hours	500	pack
	TS25CPB-LD 2.5oz Cartridge Plunger Kit	1.59" OD/ 4.00" Long	Natural/ Black	72 Hours	500	pack
	TS25C-LD 2.5oz LDPE Cartridge Only	1.59" OD/ 4.00" Long	Natural	2 Weeks	500	pack
	TS25C-GREEN 2.5oz HDPE Cartridge Only	1.59" OD/ 4.00" Long	Green	2 Weeks	500	pack
	TS1WP Cartridge Plunger Only	1.59" OD	Natural	24 Hours	10	pack
	TS1P Cartridge Plunger Only	1.59" OD	Blue	24 Hours	10	pack
	TS1PB Cartridge Plunger Only	1.59" OD	Black	24 Hours	10	pack
	TS1WP-RIB Cartridge Plunger Only	1.59" OD	Natural	24 Hours	10	pack
	TS2C 6oz End Cap Only	1.59" OD	Red	24 Hours	10	pack
	TS3P Tip Cap Threaded Seal	21mm Dia.	Red	24 Hours	10	pack
	TS6P-RED Tip Cap Threaded Seal	20mm Dia.	Red	24 Hours	10	pack
	TS216 Standard Nozzle	2.5" L x 1/16" ID HDPE	Natural	24 Hours	10	pack
	TS218 Standard Nozzle	2.5" L x 1/8" ID HDPE	Natural	24 Hours	10	pack
	TS218-LD Standard Nozzle	2.5" L x 1/8" ID LDPE	Natural	24 Hours	50	pack
	TS416 Standard Nozzle	4.0" L x 1/16" ID HDPE	Natural	24 Hours	10	pack
	TS416-LD Standard Nozzle	4.0" L x 1/16" ID LDPE	Natural	24 Hours	50	pack
	TS418 Standard Nozzle	4.0" L x 1/8" ID HDPE	Natural	24 Hours	10	pack
	TS432 Standard Nozzle	4.0" L x 1/32" ID HDPE	Natural	24 Hours	10	pack
	TS432-LD Standard Nozzle	4.0" L x 1/32" ID LDPE	Natural	24 Hours	50	pack
	TS490 Standard Nozzle	4.0" L x 3/32" ID HDPE	Natural	24 Hours	10	pack
	TS1050 Ribbon Spread Nozzle	4.0" L x 0.50" W HDPE	Natural	24 Hours	10	pack
	TS1075 Ribbon Spread Nozzle	4.0" L x 0.75" W HDPE	Natural	24 Hours	10	pack
	TS1100 Ribbon Spread Nozzle	4.0" L x 1.0" W HDPE	Natural	24 Hours	10	pack
	TS1175 Ribbon Spread Nozzle	4.0" L x 1.75" W HDPE	Natural	24 Hours	10	pack
	AD16-25 Manual Cartridge Gun	Hand Operated	Black	24 Hours	1	each
	AD16-25KIT Manual Kit Cartridge Gun	Hand Operated	Black	24 Hours	1	each
	TS16-25 Manual Cartridge Gun	Hand Operated	Black	72 Hours	1	each
	221824 Manual Cartridge Gun	Hand Operated	Silver	72 Hours	1	each
	100A-25 Pneumatic Cartridge Gun	Max. 100 PSI Air	Black	24 Hours	1	each
	TS950-25-HA Pneumatic Cartridge Gun	Max. 100 PSI Air	Black	48 Hours	1	each
	G110-25 Pneumatic Cartridge Gun	Max. 100 PSI Air	Black	72 Hours	1	each
	250255 Pneumatic Cartridge Gun	Max. 100 PSI Air	Silver	72 Hours	1	each
	AD600-25 Battery Cartridge Gun	Cordless Operated	Black	72 Hours	1	each
	TS918-25CS Retainer & Air Cap	Max. 100 PSI Air	Black	24 Hours	1	each
	918-030-000 Retainer Body Slotted	Max. 100 PSI Air	Black	24 Hours	1	each
	918-044-000 Retainer Body Non Slotted	Max. 100 PSI Air	Black	24 Hours	1	each
	918-001-004 Retainer Air Cap & Hose	Max. 100 PSI Air	Black	24 Hours	1	each
	900-2 2.5oz Syringe Filling Station	Max. 100 PSI Air	Black	24 Hours	1	each
